Model	Free Air Delivery(m3/min)*				Motor Power	Air Receiver	Compressed Air Outlet	Noise Level	Dimensions	Weight
	8bar	10bar	13bar	15bar	Kw	Litre		dB(A)**	L×W×H in mm	kg
SC-7.5	0.87	0.75	0.61	0.53	5.5	300	G1	69	800×750×900	255
SC-10	1.20	1.04	0.90	0.80	7.5	300	G1	69	800×750×900	260
SC-15	1.79	1.58	1.32	1.17	11	300/500	G1	70	900×800×1200	390
SC-20	2.40	2.15	1.84	1.66	15	300/500	G1	70	900×800×1200	400
SC-25	3.00	2.90	2.52	2.02	18.5	500	G1	71	1200×960×1300	540
SC-30	3.51	3.16	2.71	2.45	22	500	G1	71	1200×960×1300	560
SC-40	4.88	4.32	3.64	3.25	30	500	G1-1/4	71	1300×1000×1300	680
SC-50	5.83	5.21	4.44	4.01	37	500	G1-1/4	73	1300×1000×1300	700

*   according to ISO1217 part C;

** according to CAGI PNEUROP PN 8 NTC 2;

***PDP: 2-10℃

Option:

1.Compact design airend (EVO-NK);

2.Star-delta-starter (SC7,5 and SC10) ;

3.Soft starter for all models;
